  • Miele - FNS 7740 F – Refrigeration appliances - 1
  • Miele - FNS 7740 F – Refrigeration appliances - 2
  • Miele - FNS 7740 F – Refrigeration appliances - 3
Built-in freezer, 178 cm niche heightGold

FNS 7740 F

with Frost free and eight freezer drawers for maximum convenience.
sale priceINR399,990.00


Product details

  • No icing up of food and no need to defrost thanks to
    NoFrost
  • Food is frozen quickly and gently –
    SuperFreeze
  • Flexible increase in freezer volume –
    VarioRoom
  • View manufacturer details:
  • Safety Information

Product data sheet

Model identifier
FNS 7740 F
Manufacturer material number
11738280
EAN number
4002516420934
Marketing class
Gold
Freezer
Built-in appliance
Integrated appliance
Door hinge
Left
Convertible door hinging
Side-by-side enabled
Networking with Miele@home
NoFrost
VarioRoom
Cooling tips
Cooling modes
Push notifications
RemoteUpdate
Smart Home Integration
Operating concept
SensorTouch
SuperFreeze
No. of temperature zones
1
Sabbath mode
Party mode
Number of freezer drawers
8
Lock function
Acoustic door alarm
Acoustic temperature alarm
Optical door alarm
Optical temperature alarm
Power cut indication for freezer section
Niche width in mm min.
560
Niche width in mm max.
570
Niche height in mm min.
1772
Niche height in mm max.
1788
Niche depth in mm
550
Appliance dimensions (W x H x D) in mm
559 x 1770 x 546
Appliance width in mm
559
Appliance height in mm
1770
Appliance depth in mm
546
Weight in kg
63.5
Door hinge technology
Fixed door
Max. door front weight – refrigerator, in kg
26
Climate class
SN-T
4* freezer compartment in l
213
Total usable capacity in l
213
Storage time in case of fault in h
10
Sound emissions in dB(A) re 1 pW
35
Current consumption (mA)
1300
Voltage in V
220 - 240
Fuse rating in A
10
Number of phases
1
Frequency in Hz
50 - 60
Length of supply lead in m
2.2
Replacing lamps
Service
Ice cube tray
EAN
4002516420934

What's included

Ice cube tray
  • *This is a separate digital offer from Miele & Cie. KG. The range of functions can vary depending on the model and the country. Acceptance of the Terms and Conditions and Privacy Policy for Miele digital products and services in the Miele app required. Miele reserves the right to change or discontinue the digital offer at any time.
  • Cleverly networked
    Cleverly networked

    Miele@home1,

    Make your life smart: thanks to Miele@home, you can cleverly network your domestic appliances – for more options.

User convenience

Cleverly networked
Cleverly networked

Miele@home1,

Make your life smart: thanks to Miele@home, you can cleverly network your domestic appliances – for more options.
Defrosting is a thing of the past
Defrosting is a thing of the past

NoFrost

Save yourself the hassle of defrosting thanks to the recirculating air cooling system, which prevents ice from forming.

Smart Extras

  • Get more out of your refrigeration appliance
    Get more out of your refrigeration appliance

    Cooling tips1,

    Get the most out of your refrigeration appliances thanks to tips and advice in the Miele App.

  • Always up to date with software updates
    Always up to date with software updates

    RemoteUpdate1,

    Bringing new functions directly to your appliance.

  • Flexible storage for any occasion
    Flexible storage for any occasion

    Cooling Modes1,

    Quickly adapt your cooling settings to any situation with preset options.

  • Seamless networking throughout your home
    Seamless networking throughout your home

    Smart Home Integration1,

    Intelligent integration of Miele appliances into a Smart Home system.

  • Smart alerts keep you informed
    Smart alerts keep you informed

    Push notifications1,

    Maintain optimal cooling and ideal conditions with push notifications alerting you to changes.

Downloads

Product sheet
PDF
Download
User manual
PDF
Download
dwg
ZIP
Download
fbx
ZIP
Download
ifc
ZIP
Download
rfa
ZIP
Download
rvt
ZIP
Download
Energy label
PDF
Download
PNG
Download
Energy label
JPEG
Download

Whether you are looking to replace an appliance or plan a new kitchen – you will find all the relevant installation drawings for your Miele appliance here. Please note that our products should only be installed and maintained by authorised experts. In the event of queries, please ring us for some no-obligation advice!

https://media.miele.com/dam/00a6d29b-4b0f-4f27-8510-b3c300811b64/20000172143_HighresDigitalRGB.png
Descriptions
K7733E, K7763E, K7732D, K7732E, K7734F, K7764E, K7743E, K7744E, K7773D, K7774D, built-in
*The declared energy consumption was calculated in a 560 mm deep niche. The appliance is fully functional in a 550 mm niche but the energy consumption will be slightly higher.
POSTSCRIPT
Download
https://media.miele.com/dam/d12e9b0f-5b8b-478f-aafd-b3c300811b61/20000172144_HighresDigitalRGB.png
Descriptions
K7733E, K7763E, K7732E, K7734F, K7764E, K7743E, K7744E, K7773D, K7774D, side view
K7733E, K7763E, K7732E, K7734F, K7764E, K7743E, K7744E, K7773D, K7774D, side view
POSTSCRIPT
Download
  • 1.This is a separate digital offer from Miele & Cie. KG. The range of functions can vary depending on the model and the country. Acceptance of the Terms and Conditions and Privacy Policy for Miele digital products and services in the Miele app required. Miele reserves the right to change or discontinue the digital offer at any time.

We reserve the right to make technical changes; we assume no liability for the accuracy of the information provided.
