W1 front-loader washing machine:PLATINUM

WWG880 WCS PWash&TDos&Steam

A -20 % I 9 kg I 1400 rpm I SteamCare I Automatic dispensing I QuickPowerWash
sale priceINR274,990.00


Product details

  • Tested for
    20 years
    of perfect laundry care1,
  • Save even more energy with A -20 %7,
  • SteamCare
    reduces ironing time by up to 50 % and freshens up your clothes
  • Precise and automatic detergent dispensing with
    TwinDos®
    8,
  • QuickPowerWash
    ensures fast, efficient results in just 49 minutes6,
  • View manufacturer details:
  • Safety Information

Product data sheet

Model identifier WWG880 WCS PWash&TDos&Steam
Manufacturer material number 12721230
EAN number 4002516865650
Marketing class
Platinum
Suitable for stacking
Side-by-side
Slot-in
Door hinge right
Product brand W1 White Edition
Front-loader
Max. spin speed 1400
Rinse hold
Without spin function
Appliance colour Lotus white
Control panel colour Lotus white
Door design Obsidian black with chrome ring
Rotary selector colour Lotus White / Chrome ring
Control panel version 5° inclined
Control type Rotary control
Display DirectSensor white, 7 segment
Innovative PowerWash technology
TwinDos automatic detergent dispensing
CapDosing portioned dispensing
Honeycomb drum
Load in kg 9
Networking with Miele@home
SteamCare steam system
Delay start up to 24 hours
Time left display
Programme sequence indicator
AutoClean detergent drawer
AddLoad
Energy efficiency class (A–G) A
More economical than the threshold value (52) for energy efficiency class A 20%
Weighted energy consumption per 100 operating cycles for the wash cycle in kWh 40
Weighted water consumption per cycle in l 50
Spin efficiency class (A–G) B
Acoustic airborne noise emission class (spin cycle; A–D) A
Sound emissions during spin cycle in dB(A) re 1 pW 72
Duration of the “ECO 40–60” programme at nominal capacity 229
Power rating in off mode in W 0.40
Power rating in networked standby in W 0.80
Low temperature wash "Cold" and "20 °C"
Automatic load control
Flow meter
Foam sensing
ProfiEco motor
QuickPowerWash
Cottons (coloureds)
Cottons with pre-wash
Minimum iron
Delicates
Shirts
Woollens (hand-washable)
Express 20
Freshen up (steam)
Drain / Spin
ECO 40-60
Short
Pre-ironing with steam
Buzzer
Water protection system Watercontrol-System
Safety lock
PIN-Code
Optical interface
Dimensions in mm (width) 596
Dimensions (H x W x D) in mm 850 x 596 x 643
Dimensions in mm (height) 850
Dimensions in mm (depth) 643
Appliance depth in mm with opened door 1077
Weight in kg 80
Total rated load in kW 2.100-2.400
Voltage in V 220-240
Fuse rating in A 13
Frequency in Hz 50
Length of water inlet hose in m 1.60
Length of water drain hose in m 1.50
Length of supply lead in m 2
3 Caps
UltraPhase 1 + 2
Voucher for 5 Miele UltraPhase cartridges
EAN 4002516865650

What's included

3 Caps
UltraPhase 1 + 2
Voucher for 5 Miele UltraPhase cartridges
  • Smart networking

    Smart networking

    Miele@home3,

    Connect your washing machine to your home network and control it conveniently and intuitively via the app.

  • Tested for 20 years of perfect laundry care

    Tested for 20 years of perfect laundry care

    Tested for the equivalent of 20 years’ use1,

    Some car engines are subjected to 3000 hours of tests, but we test continuous performance for up to 10,000 hours.

  • Best liquid detergent system with push of a button

    Best liquid detergent system with push of a button

    TwinDos® automatic detergent dispensing4,

    Cleaner than ever: automatic dispensing with a revolutionary 2-phase system.

  • Convenient and eco-friendly dispensing

    Convenient and eco-friendly dispensing

    CapDosing portioned dispensing5,

    Easy and sustainable: optimum dispensing of special detergents, fabric conditioners and additives with CapDosing.

  • The extra-fresh, quick alternative to ironing

    The extra-fresh, quick alternative to ironing

    SteamCare steam system

    The special steam cycle reduces wrinkles, removes odours and quickly refreshes clothing.

  • Revolutionary economy with every load

    Revolutionary economy with every load

    Innovative PowerWash technology

    Clean, quick and especially energy-efficient for small loads.

Washing programs

Optimum care of synthetic fibres
Optimum care of synthetic fibres

Delicates

Gentle & soft: with the special programme synthetic textiles stay beautiful & keep their shape.
Most gentle treatment of your favourite garments
Most gentle treatment of your favourite garments

Woollens

No shrinkage, no felting: Delicate wool fabrics are cared for particularly gently, maintaining their quality.
Business as usual
Business as usual

Shirts

Prevents creasing: reduces creasing and simplifies the ironing of shirts and blouses significantly.

Quality

Tested for 20 years of perfect laundry care
Tested for 20 years of perfect laundry care1,

Tested for the equivalent of 20 years’ use1,

Some car engines are subjected to 3000 hours of tests, but we test continuous performance for up to 10,000 hours.1,

Gentle laundry care

Keep your clothing safe while tumbling
Keep your clothing safe while tumbling

Honeycomb drum

Our protective drum allows fabrics to safely glide along without snagging and damaging them.
The extra-fresh, quick alternative to ironing
The extra-fresh, quick alternative to ironing

SteamCare steam system

The special steam cycle reduces wrinkles, removes odours and quickly refreshes clothing.
Up to 50 % less ironing
Up to 50 % less ironing

Pre-ironing with steam

50 % less need for ironing – smoothing after a wash programme.

Safety

Safety thanks to an additional sensor
Safety thanks to an additional sensor

Water Control System (WCS)

WCS monitors the water intake, detects leakages and water in the floor tray.

Efficiency

Intelligent washing
Intelligent washing

Automatic load recognition

Intelligent adjustment: low load, less water and electricity consumption. Fully automatically.
Economical, powerful and maintenance-free
Economical, powerful and maintenance-free

ProfiEco motor2,

Our efficient motors with inverter drive feature technology that ensures minimal wear, noise, and energy usage.

User convenience

Smart networking
Smart networking

Miele@home3,

Connect your washing machine to your home network and control it conveniently and intuitively via the app.
Add or remove single items
Add or remove single items

AddLoad

Enjoy the flexibility to add or remove individual items during a washing cycle, without cancelling the programme.

Cleaning performance

Best liquid detergent system with push of a button
Best liquid detergent system with push of a button

TwinDos® automatic detergent dispensing4,

Cleaner than ever: automatic dispensing with a revolutionary 2-phase system.
Convenient and eco-friendly dispensing
Convenient and eco-friendly dispensing

CapDosing portioned dispensing5,

Easy and sustainable: optimum dispensing of special detergents, fabric conditioners and additives with CapDosing.
Revolutionary economy with every load
Revolutionary economy with every load

Innovative PowerWash technology

Clean, quick and especially energy-efficient for small loads.
Brilliant results in just 49 minutes
Brilliant results in just 49 minutes

QuickPowerWash

Quick and thorough: clean laundry in just 49 minutes.

Matching products and accessories

T1 heat-pump dryer:
TWH780WP 9kg

T1 heat-pump dryer:

9 kg I DirectSensor I SilenceDrum I DryCare 40 I HygieneDry

INR274,990.00
Washer-dryer stacking kit

Washer-dryer stacking kit

For space-saving and safe installation of a washer-dryer stack.

INR9,090.00
Washer-dryer stacking kit

Washer-dryer stacking kit

For space-saving and safe installation of a washer-dryer stack.

INR9,090.00
Miele UltraPhase 1

Miele UltraPhase 1

2-component detergent for whites, colours and delicates.

INR3,350.00
Descaler 250 g

Descaler 250 g

Removes harmful limescale deposits from dishwashers and washing machines.

INR1,590.00
IntenseClean – 200 g appliance cleaner

IntenseClean – 200 g appliance cleaner

For hygienic cleanliness in dishwashers and washing machines

INR1,690.00

Downloads

Product sheet
PDF
Downloads
Warranty conditions
PDF
Downloads
dwg
ZIP
Downloads
fbx
ZIP
Downloads
ifc
ZIP
Downloads
rfa
ZIP
Downloads
rvt
ZIP
Downloads

Whether you are looking to replace an appliance or plan a new kitchen – you will find all the relevant installation drawings for your Miele appliance here. Please note that our products should only be installed and maintained by authorised experts. In the event of queries, please ring us for some no-obligation advice!

https://media.miele.com/images/2000018/200001844/20000184418.png
Descriptions
W1 drawing, facia 5 degree, measures in mm
W1 drawing, facia 5 degree, measures in mm
POSTSCRIPT
Downloads
https://media.miele.com/images/2000018/200001844/20000184419.png
Descriptions
W1 drawing, facia 5 degree, measures in mm
W1 drawing, facia 5 degree, measures in mm
POSTSCRIPT
Downloads
https://media.miele.com/images/2000018/200001844/20000184420.png
Descriptions
W1 drawing, facia 5 degree, measures in mm
W1 drawing, facia 5 degree, measures in mm
POSTSCRIPT
Downloads
https://media.miele.com/images/2000018/200001844/20000184421.png
Descriptions
W1 drawing, facia 5 degree, measures in mm
W1 drawing, facia 5 degree, measures in mm
POSTSCRIPT
Downloads
  • 1.During the development phase of the W1 / W2 washing machine series, Miele tested models and core components in 5000 wash loads (= 5 wash loads per week for 50 weeks per year) in various programmes. More: miele.com/20years
  • 2.Patent EP 2 840 679
  • 3.This is a separate digital offer from Miele & Cie. KG. The range of functions can vary depending on the model and the country. Acceptance of the Terms and Conditions and Privacy Policy for Miele digital products and services in the Miele app required. Miele reserves the right to change or discontinue the digital offer at any time.
  • 4.Patent EP 2 784 205
  • 5.Patent EP 2 365 120
  • 6.This applies equally to all Miele washing machines, which are able to replicate the process and technical machine parameters laid out in the conclusion of the test report WL 1110/18.
  • 7.20 % more economical than the threshold value (52) for energy efficiency class A.
  • 8.For exclusive use with Miele UltraPhase detergent.

We reserve the right to make technical changes; we assume no liability for the accuracy of the information provided.
